F2E-320B Enclosure Cooling Fan
Frame: Aluminum alloy die-casting, surface is finished by anti-corrosion treatment with primary color or black electrophoresis.
Impeller: Metal inpellers are welded to motor rotor, and surface is finished by black electrophoresis anti-corrosion treatment.
Operation temperature/humidity range:-30℃~+65℃（temperature）0%~95%（humidity）
Protection: Motor internal with automatic recovery thermal potector.
Withstand Voltage: AC 1,800V, 1 min at 0.5mA, 50/60 Hz
Insulation Grade: Design according to IEC61858 Grade B
Rotation direction of blades:CCW seen from the front impellers
Power Connection:UL3385-22 lead wire
Unit Weight:2.9KG
